6.2. Software Tabs
The GSM Commander Setup Utility software has been designed to make the configuration process of
the GSM Commander as easy and user-friendly as possibly. With this in mind the software has been
divided into the following tabs:
➢ Numbers
➢ Messages
➢ Behaviour Statements
➢ Settings
➢ Status
➢ IO Names
➢ Analog Scaling (For Analog expansion only – in conjunction with GC-0641 or GC-1281)
➢ Lock Setup
6.2.1. Numbers Tab List A and B
This tab allows the user to program the GSM Commander with the numbers they wish the GSM
Commander to communicate with and listen to. There is a list A and list B which allows one to save
phone numbers and RFID tag numbers to the device for further functionality.
RFID tag numbers will be used when the GSM Commander is fitted with the Stealth RFID Reader
125KHz antenna (Product Code: GA100).
List A and List B provides the option to easily prioritize certain users according to the 2 groups.
ie. special ability could be granted to numbers in list A and restricted ability could be
granted to those in list B.
The FIRST number in the list A is defined as the ADMINISTRATOR number. Only the Administrator
may send configuration SMS messages to the device. (See sec 7 for more information)
Please Note: The user should adjust the sliding bar at the bottom of the screen to reserve space
for numbers to be added/removed via SMS. The numbers added/removed via sms will affect the
list B only not list A. So one cannot add or remove numbers from list A but only list B.
6.2.2. Messages Tab
This tab allows the user to program the GSM Commander with the messages they wish the GSM
Commander to respond to and respond with.
6.2.3. Behaviour Statements Tab
This tab allows the user to program the GSM Commander with a number of trigger conditions.
(See sec 8)
© Polygon Technologies. All rights reserved Page 24
