2. SPECIFICATIONS
Weight 200 grams
Dimensions
146.2 x 85,2 x 27 mm
Power Supply
12-24V DC via DC Jack
Power Consumption ~ 2.5W
Current Consumption
~ 60mA at idle (no inputs or outputs active)
Operating Temperature -30°C to +60°C
Storage Temperature -30°C to +80°C
Digital Inputs
Opto-isolated. Inputs draw 2 - 45mA, depending on
voltage. Can accept any DC signals of any type,
including:
➢ Dry Contacts
➢ Open Collector (NPN)
➢ Closed Collector (PNP)
➢ DC Voltage (3 - 20V)
Digital Outputs
2 x SPDT Relay Contact rating: 8 Amp DC (10 - 48V) or
4 Amp AC (110 – 250V). Expandable to maximum of 32*
Analog Inputs 1 x Analog input 8 bit resolution 0-10.8V / 4-20mA
IO Connector type Pluggable terminals
GSM-850/900MHz Output Power Class 4 +33dBm (2W)
GSM-850/900MHz Sensitivity -107dBm
GSM-1800/PCS-1900 Output
Power
Class 1 +30dBm (1W)
GSM-1800/PCS-1900 Sensitivity -106dBm
* Model Dependent (See Feature Matrix in Section 2 )
3. SYSTEM REQUIREMENTS
The setup software requires a PC with the following specifications:
Operating system Windows 2000 / XP / Vista / 7 / 8 /10
Computer Architecture Pentium 2 or higher IBM compatible PC
Disk space 20MB
Ports 1 x free USB port
© Polygon Technologies. All rights reserved Page 5
