4.1.1 Detailed design of FlexxPump 404DLS
The FlexxPump 404DLS consists of the following elements:
D003139
A
B
C
D
E
F
Fig.4-2 Detailed design of FlexxPump 404DLS
A Vent locking mechanism D Casing
B Covering E Connection plug for supply and control
system
C Cartridge F Hydraulic outputs
