7.3.4.3 Connect hydraulics
404DLS 3-fold
System with 3 lubrication points
D003078
A B C
F E D
Fig.7-6 Design 404DLS 3-fold
A Lubricating pinion (not included in the
scope of delivery)
D Y-segment
B Lubricating element (not included in the
scope of delivery)
E Hydraulic hose diameter of 6/3mm
C FlexxPump 404DLS F 1st axle (not included in the scope of de-
livery)
