5.3 Installing
5.3.1 Prerequisites
Dispose of the packaging in accordance with the local waste regulations.
Ü299
Checking the deliv-
ery
Check the content of the delivery by comparing it with the accompanying
documents. Check the product for damage. Report transport damage immedi-
ately.
Interfaces
Check whether the necessary interfaces exist and are functional. Order infor-
mation on the connecting cable ÜChapter11,2103.
The following interfaces are needed:
Interface 404DLS
Lubricating pinion for gear teeth and
Lubricating element for guideway
rail
X
Connecting cable M12x1, 4-pole
with the corresponding length
X
PLC X
Table5-1 Interfaces
Installation site
The following prerequisites are made for the assembly site:
• Level surface that is at least 107mm long and 45mm wide
• Sufficiently rigid
• In order to minimize condensation, the device must not be subjected to di-
rect sunlight and/or radiation heat
Commissioning
