GUDEL FlexxPump 404DLS - Fig. 5 -6 Automatic Lubrication System Flowchart; Suggested Solution: Programming

5.4.1 Suggested solution: Programming software
Start
Pump fault? /
Cartridge empty?
Set warning message**
Yes
Indicator
reached? / Manual
start?
Yes
No
No
Pump ready?*
Yes
No
Indicator
(distance; cycle number;
time)
started?
Yes
Set flag for machine stopStart lubrication cycle
Successful? (no
timeout)
Yes
No
Reset warning
Reset flag for machine stop
Set warning message**
** = Reset corresponding warning message as soon as OK again
* = No fault (5 s input) AND not empty AND lubrication cycle not started
No
Fig.5-6 Automatic lubrication system flowchart
Commissioning
OPERATING MANUAL Automatic lubrication system
FlexxPump 404DLS
99079191943154059_v10.0_EN-US
44
