5.4.7.4 Calculation formulas
The emptying time of cartridge P1 needs to be determined. With multiple
axles per FlexxPump, the axle most traveled needs to be taken into consider-
ation for the calculation (on linear gantries, this is typically the Y-axis).
The following specifications of your application are needed:
• Average velocity of the axle (vm) in m/s
• Operation time (t) of the system per day in hours
• Power-on time (POT) in %
The following values need to be calculated for P1:
Value Formula Unit
Running performance of the
axle per day (V)
vm x t x POT x 0.036 km/day
Recommended lubrication
quantity per day (P)
(V x P
t
)/ 100 cm
3
/day
Emptying time of cartridge
(P1)
Cartridge volume /
(P x 30)
months
Table5-6 Calculation formulas: Emptying time of the cartridge (P1)
The lubrication quantity calculator will help you determine the corresponding
settings and lubrication quantities for your application. The lubrication quan-
tity calculator can be found in the download area of our company website
http://www.gudel.com
Commissioning
OPERATING MANUAL Automatic lubrication system
FlexxPump 404DLS
99079191943154059_v10.0_EN-US
57
