H3C S5560S-EI Series User Manual

2-8
NOTE:
If a rack shelf is available, you can put the switch on the rack shelf, slide the switch to an appropriate
location, and attach the switch to the rack by using the mounting brackets.
Installation accessories
Table 2-3 Installation accessories for the S5560S-EI and the S5130S-HI switches
Installation accessories
S5560S-28F-EI
S5560S-52F-EI
S5560S-28P-EI
S5560S-52P-EI
S5560S-28S-EI
S5560S-52S-EI
S5130S-28S-HI
S5130S-52S-HI
S5130S-28C-HI
S5130S-52C-HI
S5560S-28S-PWR-EI
S5560S-52S-PWR-EI
S5130S-28S-PWR-HI
S5130S-28S-UPWR-HI
S5130S-52S-PWR-HI
S5130S-28C-PWR-HI
S5130S-52C-PWR-HI
Front mounting brackets (Figure 2-4) Provided Provided
Rear mounting brackets and shoulder screws (Figure
2-5)
N/A Provided
Figure 2-4 Front mounting bracket
(1) Screw hole for attaching the bracket to the switch
(2) Screw hole for attaching the bracket to the rack
1
2
