H3C S5560S-EI Series User Manual

4-43
MODE LED status
10/100/1000BASE-T
autosensing Ethernet
port LED status
Description
Steady green (Link/Active
mode)
Steady green A link is present on the port.
Flashing green The port is sending or receiving data.
Off No link is present on the port.
Flashing green (PoE mode,
available only for the
S5560S-28S-PWR-EI,
S5560S-52S-PWR-EI,
S5130S-28S-PWR-HI,
S5130S-28S-UPWR-HI,
S5130S-52S-PWR-H,
S5130S-28C-PWR-HI, and
S5130S-52C-PWR-HI
switches)
Steady green PoE power supply is normal.
Flashing green (1 Hz)
• The PoE power provided by the port
fails to meet the power requirement of
the PD.
• PoE power supply overcurrent,
overvoltage, or short-circuit occurs.
• The remaining power of the switch fails
to meet the power supply requirement
of the port.
Off
The port is not connected to a PD or PoE is
not enabled on the port.
Flashing yellow (IRF mode) Steady green
The 10/100/1000BASE-T autosensing
Ethernet port LEDs on the switch work in
conjunction to indicate the IRF member ID
of the switch. For example, if the LED for
port 5 is steady green and the other port
LEDs are off, the IRF member ID of the
switch is 5.
SFP/SFP+ port LED
Table4-13 SFP/SFP+ port LED description
SFP/SFP+ port LED status
Description
Steady green A link is present on the port.
Flashing green The port is sending or receiving data.
Off
• No link is present on the port.
• The mode LED is operating in IRF mode.
• The mode LED is operating in PoE mode (only for PoE switches).
Management Ethernet port LED
Table4-14 Management Ethernet port LED description
Management Ethernet port LED (ACT/LINK) status Description
Steady green A link is present on the port.
Flashing green The port is sending or receiving data.
Off No link is present on the port.
