4-34
4 Ports and LEDs
Ports
Console port
The switch has two console ports: a serial console port and a Micro USB console port.
Table4-1 Console port specifications
Item Serial console port Micro USB console port
Connector type RJ-45 Micro USB Type B
Compliant standard EIA/TIA-232 USB 2.0
Transmission baud rate 9600 bps (default) to 115200 bps
Services
• Provides connection to an ASCII terminal.
• Provides connection to the serial port of a
local PC running terminal emulation
program.
Provides connection to the
USB port of a local PC running
terminal emulation program.
Management Ethernet port
All S5560S-EI and S5130S-HI switches except the S5560S-52F-EI switch each provide a
management Ethernet port on the front panel. You can connect this port to a PC or management
station for loading and debugging software or remote management.
Table4-2 Management Ethernet port specifications
Item Specification
Connector type RJ-45
Connector quantity 1
Port transmission rate
10/100 Mbps, half/full duplex
MDI/MDI-X, autosensing
Transmission medium and max
transmission distance
100 m (328.08 ft) over category-5 twisted pair cable
Functions and services Switch software and Boot ROM upgrade, network management
USB port
All S5560S-EI and S5130S-HI switches except the S5560S-28F-EI and S5560S-52F-EI switches
each have one OHC-compliant USB2.0 port that can upload and download data at a rate up to 480
Mbps. You can use this USB port to access the file system on the flash of the switch, for example, to
upload or download application and configuration files.
