H3C S5560S-EI Series User Manual

4-42
Power supply status LED
The switch provides two power supply slots at the rear. For each power supply, the switch provides a
power supply status LED on the front panel.
Table4-10 Power supply status LED description
LED mark Status Description
PWR1/PWR1
Steady green
A power supply is installed in the power supply slot, and the power
supply is outputting power correctly.
Steady yellow
A power supply is installed in the power supply slot, but the power
supply has failed or no power is input to the power supply.
Off No power supply is installed in the power supply slot.
Mode LED (MODE)
All S5560S-EI and S5130S-HI series switches except the S5560S-28F-EI and S5560S-52F-EI
switches each provide a mode LED (MODE) to indicate the type of information that the
10/100/1000BASE-T autosensing Ethernet port LEDs are showing.
You can use the LED mode switching button to change the indication of the mode LED.
Table4-11 Description for the mode LED
LED mark Status Description
MODE
Steady green
The 10/100/1000BASE-T autosensing Ethernet
port LEDs indicate the link and operating status
of the port.
Flashing green (available only for the
S5560S-28S-PWR-EI,
S5560S-52S-PWR-EI,
S5130S-28S-PWR-HI,
S5130S-28S-UPWR-HI,
S5130S-52S-PWR-HI,
S5130S-28C-PWR-HI, and
S5130S-52C-PWR-HI switches)
The 10/100/1000BASE-T autosensing Ethernet
port LEDs indicates the PoE power supply status
of the ports.
Flashing yellow
The 10/100/1000BASE-T autosensing Ethernet
port LEDs indicates the IRF member ID of the
switch. For example, if the LED for port 5 is
steady green and the other LEDs are off, the IRF
member ID of the switch is 5.
10/100/1000BASE-T autosensing Ethernet port LED
The switch provides a status LED for each 10/100/1000BASE-T autosensing Ethernet port. The port
LED and the MODE LED work in conjunction to indicate the operating status of the
10/100/1000BASE-T autosensing Ethernet port.
Table4-12 10/100/1000BASE-T autosensing Ethernet port LED description
MODE LED status
10/100/1000BASE-T
autosensing Ethernet
port LED status
Description
