H3C UniServer R4700 G6

13
No.
Description
11 Front I/O connector (RIGHT EAR)
12 M.2 SSD AUX connector (M.2 AUX)
13 Fan module connector 8 (FAN8)
14 LCD smart management module connector (DIAG LCD)
15 MCIO connector C1-P4A (x8 PCIe5.0, for processor 1)(C1-P4A)
16 Fan module connector 7 (FAN7)
17
MCIO connector C1-P4C (x8 PCIe5.0, for processor 1)(C1-P4C)
18 Fan module connector 6 (FAN6)
19 MCIO connector C1-P3C (x8 PCIe5.0, for processor 1)(C1-P3C)
20 Fan module connector 5 (FAN5)
21 MCIO connector C1-P3A (x8 PCIe5.0, for processor 1)(C1-P3A)
22 Front drive backplane power connector 3 (PWR3)
23 Front drive backplane power connector 2 (PWR2)
24
Front drive backplane power connector 1 (PWR1)
25 Fan module connector 4 (FAN4)
26 MCIO connector C2-P4A (x8 PCIe5.0, for processor 2)(C2-P4A)
27 MCIO connector C2-P4C (x8 PCIe5.0, for processor 2)(C2-P4C)
28 Fan module connector 3 (FAN3)
29 Fan module connector 2 (FAN2)
30 Front drive backplane AUX connector 2 (AUX2)
31 Front drive backplane AUX connector 1 (AUX1)
32 Fan module connector 1 (FAN1)
33 Chassis-open alarm module connector (INTRUDER)
34 Front VGA and USB 2.0 connector (LEFT EAR)
35 Rear drive backplane power connector 4 (PWR4)
36 Rear drive backplane power connector 5 (PWR5)
37
MCIO connector C2-P2C ( for processor 2)(C2-P2C)
38 Rear drive backplane AUX connector 5 (AUX5)
39 MCIO connector C2-P2A (for processor 2)(C2-P2A)
40 Riser card AUX connector 8 (AUX8)
41 NVMe VROC module connector (NVMe RAID KEY)
42 Embedded USB 2.0 connector (INTERNAL USB2.0)
43 System battery
44
MCIO connector C1-P2C (for processor 1)(C1-P2C)
45 MCIO connector C1-P2A (for processor 1)(C1-P2A)
X System maintenance switch (MAINTENANCE)
x8 PCIe5.0 description:
