Figure 63 Create an SNMP view (1)
4. Enter the view name.
5. Click Apply.
The page in Figure 64 appears.
Figure 64 Create an SNMP view (2)
6. Configure the parameters as described in Table 38.
7. Click Add.
8. Repeat steps 6 and 7 to add more rules for the SNMP view.
9. Click Apply.
To cancel the view, click Cancel.
Table 38 Configuration items
Item Descri
tion
View Name Set the SNMP view name.
Rule
Select to exclude or include the objects in the view range determined by the MIB
subtree OID and subtree mask.
MIB Subtree OID
Set the MIB subtree OID (such as 1.4.5.3.1) or name (such as system).
MIB subtree OID identifies the position of a node in the MIB tree, and it can uniquely
identify a MIB subtree.
Subtree Mask
Set the subtree mask.
If no subtree mask is specified, the default subtree mask (all Fs) will be used for
mask-OID matching.
