그림 2 유압 접속부 개요
1 샘플 튜브(주황색 피팅) 6 배관 연결부
2 주사기 펌프 7 시약병
3 오존 필터 8 자외선 반응기
4 시약 튜브(녹색 피팅) 9 배출 튜브
5 탈착 가능한 드립 트레이 10 GLS(Gas Liquid Separator) 용기
제품 구성품
그림 3 참조하여 제품 구성품을 모두 확인합니다. 품목이 누락되었거나 손상된 경우에는 제조업체
또는 판매 담당자에게 즉시 연락하시기 바랍니다.
102
한글
