图 2 液壓連接概覽
1 取樣管 (橘色管件) 6 管道連接圖
2 注射泵 7 試劑瓶
3 臭氧過濾器 8 UV 反應器
4 試劑管 (綠色管件) 9 排水管
5 可拆卸式滴水盤 10 GLS (氣液分離器) 水容器
產品元件
確認已收到所有的元件。請參閱 图 3。若有任何物品遺漏或損壞，請立即與製造商或業務代表聯絡。
