Figure 2 Hydraulic connections overview
1 Sample tube (orange fitting) 6 Plumbing connections map
2 Syringe pump 7 Reagent bottle
3 Ozone filter 8 UV reactor
4 Reagent tube (green fitting) 9 Drain tube
5 Removable drip tray 10 GLS (Gas Liquid Separator) water vessel
Product components
Make sure that all components have been received. Refer to Figure 3. If any items are missing or
damaged, contact the manufacturer or a sales representative immediately.
