40 Chapter 2, Equipment Description
P/N 120745-IE, Manual revision: AA Haemonetics
®
Cell Saver
®
Elite
®
User Manual
During the Wash phase, the Wash pad expands to show the wash volume
used and the target wash volume.
Figure 12, Example of the Wash pad during the Wash phase
To change the target wash volume for the current cycle:
1. Touch Cycle Wash Volume. The Cycle Wash Volume box appears.
2. Use the +/- pads to increase or decrease the target wash volume for the
current wash cycle:
3. Touch (Accept) to save the change or (Cancel) to exit.
Figure 13, Example of the Cycle Wash Volume box
1.
2.
1. Target wash volume
2. Wash volume used
2.
1.
3. 4.
1. Decrease
2. Increase
3. Cancel
4. Accept
