13. Closing the charging station
x 8
2 N.m max
T25S
2 N.m max
Respect the
tightening torque;
risk of losing IP55
protection.
1. Select the
correct sticker.
Sticker to be used
when the locking
key is not used
2. First remove the back of
the sticker.
3. Adjust the sticker in the
intended area.
4. Remove the protective film
from the front of the sticker.
Sticker to be used
when the locking
key is used
