EB+ Soft Docking Installation guide
24
Innovative Vehicle Solutions 2020
Installation error
Care must be taken when choosing the location and orientation of the sensor on the trailer to ensure that the
sensor detection zone does not clash with any part of the trailer and / or floor, especially when using the sensor
offset.
Example: Sensor mounted using the sensor software offset
Sensor detection zone clashes with the floor
(red shaded area)
Sensor detection zone clashes with the bottom
of the trailer (red shaded area)
