Haldex EB+ Soft Docking - Part Reference; EB+ Soft Docking ECU; LED Outline Marker Lamp (Visual Warning Signals)

EB+ Soft Docking Installation guide
52
Innovative Vehicle Solutions 2020
Part reference
These available service parts can be obtained from Haldex service centres or distributors.
EB+ Soft Docking ECU
The ECU receives sensor information, determines the system status, and
sends it to the EBS via the trailer CAN.
EB+ Soft Docking ECU Part number
ECU 364 608 001
Green connector Brown connector
LED outline marker lamp Part number
Left side 364 617 001
Right side 364 617 011
Left side - superseal connector 364 617 101
Right side - superseal connector 36 4 617 111
Led outline marker lamp (visual warning signals)
Used to warn the driver of the distance to the obstacle via flashes
dependent on distance .
