EB+ Soft Docking Installation guide
46
Innovative Vehicle Solutions 2020
Conditions of no detection
The system will not detect the loading dock when:
› The system is not properly connected to EB+ Gen3
› The vehicle is not in reverse gear
› The vehicle speed exceeds 15 Km/h
› EB+ Gen3 is not operating
If the trailer is driven at an angle to the dock, it is possible for the sensor not to detect the dock. Some materials
like textiles weaken the ultrasonic signals, significantly reducing the sensing distance.
The system cannot replace the driver’s responsibility to ensure a clear passage when manoeuvring. The operation
needs to be tested on a vehicle after installation.
The vehicle requires Haldex EB+ Gen3 2M or 3M systems to function.
Day time mode activation
After engaging the reverse gear the LED outline markers are turned on.
At a distance to the obstacle greater than 2.5 m, the LED outline markers are on, and the buzzer is silent.
At a distance to the obstacle less than 2.5 m, the system switches to the indication modes (see page 26).
Night silent mode activation
If the reverse gear is engaged twice (within 2 seconds) the audio beeper will be set to ‘’night silent’’ mode. The
‘’night silent’’ mode is to prevent audible nuisance at night in residential areas.
The LED outline markers are still active as usual.
