EB+ Soft DockingInstallation guide
3
2020 Innovative Vehicle Solutions
Contents
Introduction ...............................................................4
Chassis components
.................................................. 5
Sensor cables
........................................................... 12
Installation of EB+ Soft Docking ECU
....................... 14
Installation of LED outline marker light
..................... 15
Installation of audio beeper
...................................... 16
Installation of power supply adapter cable
............... 17
Installation of ultrasonic sensor
................................ 18
Configuring EB+ Soft Docking using DIAG+
............. 25
Functional test
......................................................... 44
Operating instructions
.............................................. 45
Conditions of no detection
...................................... 46
Error repair
.............................................................. 48
Liability exclusion
..................................................... 49
Excess cable
............................................................. 50
Painting
................................................................... 51
Part reference
.......................................................... 52
