EB+ Soft DockingInstallation guide
49
2020 Innovative Vehicle Solutions
Liability exclusion
The system is not 100% accurate under all circumstances. When using the EB+ Soft Docking system the driver
must manoeuvre with care and attention up to the dock / ramp. Haldex cannot be held responsible for any
damage that may occur when using the system. It is the always the drivers responsibility to reverse / manoeuvre
safely.
Cable connections
Ensure that the EB+ Soft Docking ECU connectors are plugged into the correct colour coded cable connectors,
and with the correct polarity.
Ensure that the EB+ CAN cable is only plugged into the EB+ Gen3 CAN connectors, and with the correct polarity.
Any deviations will void any warranty claims.
Green connector Brown connector
EB+ CAN cable connection
