EB+ Soft Docking Installation guide
56
Innovative Vehicle Solutions 2020
Sensor splitter cable A B C
364 607 001 0.5 m 0.5 m 0.5 m
A
B
C
Sensor splitter cable
Y cable to add additional sensors
Sensor splitter cable A
364 622 001 1.0 m
364 622 011 3.0 m
364 622 021 6.0 m
A
Sensor extension cable
Cable to increase the sensor distance from the ECU
Refer to customer drawings for cable dimensions
Refer to customer drawings for cable dimensions
