Symptoms and Problems
Finding the Problem – Before Getting Inside
Please note that most technical problems that can occur with the C800/C1000 occur with
external system components. The following are the key components to check before removing
any lift cover:
• Charger and Charge Connections
• Hand Control and Airline Problems
• Twisted Strap or Slack Tape Issues
• External Thermal Breaker
• Review Trouble Shooting Points in Owner’s Manual
The ceiling lift is a pneumatically operated electro-mechanical device. To diagnose performance
interruption, it is useful to think of the product as three separate systems:
• Pneumatic System
o Hand Control Unit
o Airline Tubing (2, 4, 6-way)
o Grommet Connectors
o Connector Pins
o Air Tubes
o Air Receiver Mechanism
• Electrical System
o Charger and Charger Connections
o Main PCB – Printed Circuit Board
o Wire Harnesses
o Microswitch Up Limit Switch
o Microswitch Down Limit switch
o Quick Disconnects
o LED Indicator & LCD Display
o Electric ON/OFF, Emergency Lowering and Emergency Shut-Off
• Mechanical System
o Carry Bar or Lifting Hook
o Lifting Strap
o Tape Switch Assembly
o Motors and Gears
o Trolley Wheels
