Note: For more information on and instructions for these parts of the gear unit,
refer to the certified drawing and the service manual of the lubrication and
cooling system:
• Lubrication system
• Instrumentation
• Settings
Instructions for force-feed lubrication (integrated pump)
Note: During startup, it is necessary to delay the alarm signal.
Procedure
1. Adjust the flow switch to make sure that the motor that operates the gear unit stops
when the oil flow is less than the alarm level.
Instructions for force-feed lubrication (pump with a motor)
Caution: Make sure that the motor of the pump turns in the correct direction. If
not, the gear unit is not lubricated correctly. This condition causes damage to
the gear unit.
Procedure
1. Refer to the service manual of the lubrication and cooling system.
Instructions for force-feed lubrication (pressure lubrication)
Procedure
1. Refer to the service manual of the lubrication and cooling system.
Fill the gear unit with gear oil
Select the gear oil
Caution:
• Only use the gear oil that agrees with the type plate and with section
Lubricants
on page 61. Do not use another type of gear oil.
• Only use the markings on the dipstick to measure the gear oil level.
• Make sure that all items that can cause draining of the gear oil by accident
are secured
Note:
• H.I.T. is not responsible or liable if the supplier of oil changes the
composition of the gear oil.
• It can be necessary to rinse the gear unit. Speak to the supplier of the gear
oil.
8.12.2
8.12.3
8.12.4
8.13
8.13.1
Installation
IM_405_002_EN
39
