Hansen P4 - 13 Technical Data; Dimensions and Mass; Materials of the Gear Unit; Torque Seal Specification

Technical data
Dimensions and mass
Refer to the certified drawing.
Materials of the gear unit
• Gear oil
• Grease
• FKM (a type of fluoroelastomer)
• Copper
• Aluminium
• Polycarbonate (solid)
• Polypropylene (with embedded glass fibre or with carbon)
• Polyamide (solid)
• Polyphenol sulfide (solid)
• For information on the paint and other materials, refer to the drive package
documentation.
Torque seal specification
Parameter
Specification
Torque seal Loctite 7417 torque Marque or similar
Paint specification
Parameter
Specification
Primer Two-component, polyamide-cured epoxy pre-
fabrication primer (20µm)
Finish Two-component, high build, polyamine adduct-
cured epoxy coating (200µm)
Total average minimum dry film thickness 220µm
Corrosion protection by H.I.T.
Parameter
Specification
Inner parts Rust preventive mineral oil
Breather plug Present but not sealed
Shaft extensions Rust preventive grease
Hollow shafts Anti-oxidising waxy varnish
Unpainted machined surfaces Anti-oxidising waxy varnish
13
13.1
13.2
13.3
13.4
13.5
Technical data
