Table for bolts according to SAE bolt quality grade 5
Gear unit type Gear unit size Bolt dimension [UNC] Torque [lbf.in]
QV A 5/8" 1550
B 3/4" 2950
C 1" 6000
D 1 1/8" 10300
E 1 1/4" 12000
F 1 1/2" 21000
G, 2-stage 1 1/2" 21000
G, 3-stage and 4-stage 1 3/4" 33650
H 1 3/4" 33650
J 1 3/4" 33650
K 1 3/4" 33650
L 2" 50750
M 2" 50750
N 2" 50750
P 2" 50750
Q 2" 50750
R 2 1/4" 81050
S 2 1/4" 81050
T 2 1/4" 81050
Torque values for oil drain screw
Dimension of the drain screw Torque
G ½ " 56,5 Nm
G ¾ " 73,4 Nm
≥ G 1 " 79 Nm
Shrink disk specifications (2-part shrink disk)
Lubrication
Parameter Specification
Lubricant Molykote D321R or similar (friction coefficient:
0.04)
13.11
13.12
13.12.1
Technical data
58
IM_405_002_EN
