Hansen P4 - Bolt Specifications (Multi-Stage, Horizontal LSS)

Bolt specifications (multi-stage, horizontal LSS)
Table for bolts according to DIN 267 bolt quality grade 8.8
Gear unit type Gear unit size Bolt dimension [ISO] Torque [Nm]
QH... A M16 180
B M20 335
C M24 675
D M24 675
E M30 1350
F M30 1350
G M36 2350
H M36 2350
J M36 2350
K M36 2350
L M42 3800
M M42 3800
N M48 5700
P M48 5700
Q M48 5700
R M56 9150
S M56 9150
T M56 9150
