MAIN PARTS
CONTROL BOX
31. Emergency stop button
32. Drive lamp
33. Thread break lamp
34. Display (L.C.D.)
35. Menu button
36. Forward button
37. Arrow button (Up, Down,
Left, Right)
38. Enter button
39. Pressure foot button
40. Thread cut button
41. Needle change button
42. Speed control button
43. Start button
44. Stop button
45. Contrast control dial
46. Memory card eject button
47. Memory card slot
48. USB memory port
BOBBIN WINDING
49. Upper Thread guide
50. Thread stand pin
51. Thread stand felt
52. Thread guide
53. Thread tension
54. Spindle
55. Lever
