SETTING UP THE MACHINE
Accessories
Please confirm you have received the following.
2_2 K101
2-2
1. Thread guide bracket
2. Thread guide pillar (2 pcs)
3. Thread stand
4. Thread stand felt (13 pcs)
5. Thread stand pin (13 pcs)
6. Wave washer (13 pcs)
7. Carriage
8. Frame base
9. Embroidery frame (square) PTA-32320-360
10. Embroidery frame (Round)
PTA-15-360
11. Needle (DB X K5) (10 pcs)
12. Oiler
13. Sewing machine oil
14. CD-ROM (Happy Link)
15. CD-ROM (Instruction manual, Parts list)
16. Instruction book (How to open the CD-ROM)
17. USB cable
18. Power line cord ass'y (A shape will be changed
depending on a destination)
19. Fuse (6A)
20. Off set screw driver HCB53050
21. #2 (+) Screw driver HCB53011
22. 2 mm (-) Screw driver HCB53020
23. 3 mm hexagonal driver HCB53130
24. 2.5 mm hexagonal driver HCB53120
25. Brush HCB53070
26. Manual lever
Tools
1
2
463
78
9
10 11
12 13
15 16
20
21
22
23
24
5
25
26
17 18 19
14
