HI 1756-WS WEIGH SCALE MODULE

3-8

RTA Cable

Assembly

• Six (6) foot cable that connects to the HI 1756-

WS module.

FIG. 3-10 RTA CABLE ASSEMBLY - HI 1756WS

SINGLE CHANNEL

FIG. 3-11 RTA CABLE SCHEMATIC - HI

1756WS SINGLE CHANNEL

• Six (6) foot cable that connects to the HI 1756-

2WS module

FIG. 3-12 RTA CABLE ASSEMBLY - HI

17562WS DUAL CHANNEL
