Chapter 4 - Setup
4-17
NOTE: * Required Command Data
* * Available only with the HI 215IT Junction Box.
Search for C2
Load Sensors
(C2SEARCH)
Searches for C2 Load Sensors
Command Number: 0x6E (Hexadecimal)
Channel Number: 0 or 1
Number of Elements: 8
Return Values:
• COMMAND
• CHANNEL
•STATUS
• C2ROM - The number of C2 sensors detected.
• C2SWITCH - The number of JBOX switches
detected.
• CAPACITY - Combined sensitivity of C2 load
cells.
• SENSITIVITY - Combined sensitivity of C2 load
cells.
Read C2 Sensor
Serial Number
(READC2SERIALN
UM)
Reads the serial number of a specified C2 load sensor.
Must be preceded by the C2SEARCH command.
Command Number: 0x70 (Hexadecimal)
Required Command Data:
• COMMAND
• CHANNEL
• SENSOR # (0-7 Number of specific Load Cell
Requested)
• Number of Elements: 12
REAL weight_4** Gross Weight, load cell 4
Structure Item Description
