HI 1756-WS WEIGH SCALE MODULE
4-16
Structure
(ITECHTEST)
Structure Item Description
DINT command* 0x66
DINT channel* 0 or 1
DINT status* N/A
DINT nSensors* Number of load sensors.
REAL BaseR Load cell impedance measured during Calibration
REAL ReadR Impedance measured at test time
DINT TestR Test Result: Good = True, Bad = False
REAL Vsense Sense Voltage from the load cells
REAL loadcell current Load Cell Current
DINT RTZ_R_combined Test result, return to zero, all load cells
DINT RTZ_R_1** Test result, return to zero, load cell 1
DINT RTZ_R_2** Test result, return to zero, load cell 2
DINT RTZ_R_3** Test result, return to zero, load cell 3
DINT RTZ_R_4** Test result, return to zero, load cell 4
REAL DVM_combined Millivolts/Volt, all load cells
REAL DVM_1** Millivolts/Volt, load cell 1
REAL DVM_2** Millivolts/Volt, load cell 2
REAL DVM_3** Millivolts/Volt, load cell 3
REAL DVM_4** Millivolts/Volt, load cell 4
REAL IREF_weight Internal reference counts, converted into a weight
REAL JBOXREF_weight JBOX reference counts, converted into a weight
REAL grossweight Combined Gross Weight, all load cells
REAL weight_1** Gross Weight, load cell 1
REAL weight_2** Gross Weight, load cell 2
REAL weight_3** Gross Weight, load cell 3
