HI 1756-WS WEIGH SCALE MODULE
4-8
Parameters for the HI
1756-WS (-2WS)
Module
NOTE: The Glossary at the end of this manual provides addi-
tional information about the parameters and other
common weigh process definitions.
All parameters in Table 4-1 are either type DINT (4-
byte integer) or REAL (4-byte floating point).
STATUSCMDERROR 0x4000 Output Table Command Failed
STATUSCHANENABLED 0x8000 Set if channel is enabled
Word Number Definition
# Type Parameter Description
1 DINT ChanActive Flag, determines if a channel is alive.
Legal values are: 0 (Channel Off) or 1
(Channel On)
2 DINT calyear Year of last Calibration*
3 DINT calmonth Month of last Calibration*
4 DINT calday Day of last Calibration*
5 DINT[2
]
calid[2] ID of calibrator using initials. e.g. JB*
6 DINT CalibType Read Only
Button = 3
C2 = 1
Hard Cal = 0
Never Calibrated = FFFF
7 REAL tareweight Tare weight in lbs or kgs as determined
by Metric.
8 DINT Metric Report weight in lbs or kgs.
Legal Values
lbs = 0
kgs = 1
TABLE 4-1: PARAMETERS
