Chapter 4 - Setup
4-9
NOTE: *Since the 1756 module has no real-time clock, the
operator must set the year, month, day, and calid.
9 DINT Waversaver Legal Values are 0-4
0 = 7.5 Hz
1 = 3.5 Hz
2 = 1 Hz
3 = .5 Hz
4 = 0.25 Hz
10 REAL SpanWeight Calibration weight, high, in lbs or kgs
11 REAL CalLowWeight Calibration weight, low, in lbs or kgs
12 DINT NumAverages Legal Values: 1-255
13 DINT ZeroTrackEnable Enable for Zero Tracking
Legal Values:
0 = Not Enabled
1 = Enabled
14 DINT ROCTimeBase Legal Values: 1-1800 seconds
15 REAL ZeroTolerance In lbs or kgs.
16 REAL AutoZeroTolerance In lbs or kgs
17 REAL MotionTolerance In lbs or kgs
# Type Parameter Description
TABLE 4-1: PARAMETERS
