5-2 Extension cable wire bound specifications
5-4
4
5
Options
(3) For brakes (EWA-B××-JST03-TMC)
Actuator side Power supply side for brake
Pin NO. Wire color Wire color Connector
1 Red
Red, black
(nonpolar)
Round crimp-style
terminal 1.25-4
With insulating coating
2 White
3 Black
Connector
Retainer: PMS-03V-S
Housing: PARP-03V
Contact: S(B)PA-001T-P0.5
J.S.T. Mfg Co.,Ltd
