Chapter 5 Maintenance and Troubleshooting Audio Video Processing Modules (AVPM)
© 2015 Harmonic Inc. All rights reserved. 49 Electra 9200, Rev O
Figure 5–13: Removing an AVPM
6. Grab the card handle and slide the card from the chassis, as shown in Figure 5–13.
6
5
(RN-19)
