4C20 Gasoline Engine Repair Manual
(b) The bolts are loosened in the opposite order to that shown in the figure.
(a) Gently insert a flathead screwdriver into the narrow groove
between the bearing shell of the cylinder block and remove
3. Remove the cap and main bearing shell
1. Remove bushing
insert.
crankshaft position.
Note:
Advice:
Advice:
ÿ The removed crankshaft position sensor drive disk and its fastening
screws must be replaced.
ÿ The removed bushing O-ring must be replaced
ÿ Mark where the earbuds should be placed and fold
those by their groups.
change.
2. Remove the main bearing cap
4. Remove the crankshaft position sensor drive disk
(a) Remove the 10 main bearing cap bolts and the 6 cylinder block
horizontal pinch bolts securing the main bearing caps;
(a) Loosen the three screws and remove the sensor drive disk
shaft
102
Disassembly
