HAVAL 4S20 - Section II. Coolant Pump

4C20 Gasoline Engine Repair Manual
3
5
4
6
38
Section II. coolant pump
7 - Electric pump of the cooling system
2 — a sealing ring of the case of the pump of system
5 — a Belt of a drive of the pump of system of cooling
8 - Inlet hose of the electric pump of the system
cooling
we're chilling3 - O-ring of the pump of the cooling system
nia
6 — a casing of a belt of a drive of the pump of system of cooling1 — The case of the pump of system of cooling
4 — the Pump of system of cooling
