Chapter V. Turbocharging System
(a) Remove the 3 bolts and remove the heat shield you
(c) Remove 2 bolts.
turbocharger cooling
Attention:
(d) Remove section II of the turbocharger cooling system outlet
pipe
start manifold.
(a) Before disassembling the turbocharger, drain the engine oil
and coolant
2. Removing the vacuum hose I and outlet hose I of the
turbocharger cooling system
(a) Loosen the 4 clamps and remove the hose.
(a) Loosen 4 clamps.
1. Removing the exhaust manifold heat shield
(b) Remove bolt (A).
3. Removal of section II of the discharge pipeline of the system
17
Section II. Turbocharger
Disassembly
A
B
