4C20 Gasoline Engine Repair Manual
(a) Remove the 1 bolt fitting of the turbocharger oil inlet pipe
from the turbo inlet side
4. Removing the inlet pipe of the cooling system of the
supercharger tour
Clue:
supercharger.
ÿ Do not reuse the gaskets of the oil inlet and outlet pipe bolts.
(a) Remove the bolt (A) and the 2 inlet and outlet pipe union
bolts (B), and remove the turbocharger.
turbocharger.
ÿ Loosening the bolt may cause engine oil to leak out. Use a
suitable container to catch the oil.
ÿ Loosening the bolts of the oil inlet and outlet pipes may cause
engine oil to leak out. Use a suitable container to catch the
oil.
Clue:
ÿ Keep parts clean. Don't let it hit
dust on them.
6. Removing the turbocharger mounting bracket
ÿ Do not reuse the gaskets of the inlet and outlet pipe bolts.
(b) Loosen the bolt (1) and remove the turbocharger oil feed
pipe
(c) Remove the 4 bolts (shown by arrows), remove the
turbocharger oil outlet pipe and 2 gaskets.
(b) Loosening the inlet and outlet pipe bolts may cause coolant
to leak out. Use a suitable container to catch the liquid.
(a) Remove 2 bolts and turbo mounting bracket
supercharger.
5. Removing the inlet and outlet oil pipes
Note:
turbocharger
ÿ Do not reuse the oil return pipe gasket.
(d) Keep foreign matter out of the inside
18
