4C20 Gasoline Engine Repair Manual
(a) Set the 12.5mm torque wrench to point A, turn the tensioner clockwise to the
end position (when viewed from the front of the engine), and remove the V-
ribbed belt.
2. Remove the power steering pump
nia
1. Removing the V-ribbed belt
(a) Check the reliability of the fluid piping connection.
4. Checking the power steering pump
6. Assembly in the reverse order of removal.
(a) See Section II. V-ribbed belt, page 8.
ki.
3. Checking the V-ribbed belt
5. Checking the presence and serviceability of the fixing sleeve
ÿ Tightening torque: 22±2 Nm.
(b) Check for abnormal sounds during power steering pump operation. If abnormal
sounds are present, the power steering pump must be replaced.
(a) Remove the 3 bolts and remove the pump.
power steering bones.
Disassembly
Assembly
Section VI. Power steering pump
Examination
12
