HAVAL 4S20 - Section V. Balance Shaft

4C20 Gasoline Engine Repair Manual
Note:
tea needed.
ÿ The balance shaft must only be removed when
ÿ Do not reuse a removed bushing.
2. Remove the toothed pulley of the pump drive of the system
1. Remove the balance shaft from the exhaust side
(a) Loosen one bolt and remove the balance shaft from
getting along
(a) Loosen the coolant pump drive sprocket bolt and remove
the sprocket from the inlet side of the balance shaft.
release sides;
(b) Remove the balance shaft bushing from the side you
Advice:
start.
ÿ The coolant pump drive sprocket bolt is turned out clockwise.
3. Remove the idler gear (a) Loosen the
balance shaft idler gear bolt and remove the gear.
108
Disassembly
Section V. Balance Shaft
