ÿ Tightening torque: 22±2 N•m
5. Assembly in the reverse order of removal.
coming out of the grooves.
1. Removing the V-ribbed belt
4. Checking the air conditioning compressor
(a) Set the 12.5mm torque wrench to point A, turn the tensioner clockwise to
the end position (when viewed from the front of the engine), and remove
the V-ribbed belt.
2. Removing the air conditioning compressor
3. Checking the V-ribbed belt
(a) See Section II. V-ribbed belt, page 12.
(a) Check the tightness of the grooves of the compressor pulley
(a) Remove the 3 bolts and remove the A/C compressor.
with poly V-belt teeth.
(b) Make sure that the serpentine belt does not slip
ÿ
Disassembly
Assembly
Section IV. Air conditioning compressor
Examination
Detachment ÿÿ
Crack at the
base of the tooth
Crack
canvases
Side crack
10
4C20 Gasoline Engine Repair Manual
