4C20 Gasoline Engine Repair Manual
(a) Remove the engine oil pressure sensor.
(e) If the engine oil pressure is not correct,
3. Engine oil pressure check
(b) Install the oil pressure gauge (A) to the location of the dates
perform the following checks:
chika (B).
1. Checking the correctness of the engine oil
(1) Check if the oil intake strainer is clogged
Nika.
(a) Check engine oil specification and viscosity for ambient
temperature. Change oil if necessary.
(c) Warm up the engine to normal operating temperature
(90-100°C).
(1) Check the engine oil pressure.
2. Checking the engine oil level
(2) Check the operation of the oil pump.
ÿ ÿ75 kPa at idle;
(a) 15 to 20 minutes after stopping a warm engine, the engine oil
level should be between the maximum and minimum marks.
If the level is below the minimum mark, check for oil leakage
and add oil to the maximum mark.
ÿ 245-539 kPa at 3000 - 5500 rpm
(d) Remove the oil gauge.
48
Section II. Engine oil
Examination
Minimum level Max Level
BAR
