(a) Install the cylinder head cover oil outlet pipe (B) to the appropriate
positions on the bearing cap and secure with bolts (A).
(c) Tightening sequence:
18. Installing the hot water outlet
ÿ Tightening torque: 10±1 Nm.
(1) Bolts 23-1.
liquids
firewood and secure with 2 bolts.
ÿ Tightening torque: 10±1 Nm.
(a) Check the condition of the O-ring.
(2) Bolts 24-29.
(d) Tightening torque:
(b) Install the pipe on the cylinder head and secure with bolts.
ÿ Tightening torque: 10±1 Nm
ÿ Bolts 1-3: 22±2 N•m
ÿ Bolts 4-29: 10±1 N•m
(c) Make sure the air inlet (1) is installed in the direction of the intake valves.
17. Installation of the outlet oil pipe of the cylinder head cover
19. Installation of the outlet oil pipe of the cylinder head
(a) Install the oil outlet pipe to the cylinder block
70
4C20 Gasoline Engine Repair Manual
