Chapter X. Cylinder head
Motor
wire
oil
Motor
Engine oil
oil
steel wire
oil
Steel
wire
steel wire
Steel
Motor
77
5. Place the valve lash adjuster in container B and use
0.5mm diameter steel wire and slowly push the steel ball
5-10 times to drive the plunger. Continue the above steps
until the plunger moves smoothly. This will help clean the
high pressure chamber of the hydraulic lifter.
8. Raise the plunger and set the hydraulic compensator
vertically, press the plunger to its extreme position and
slowly return it to its original position. Then lightly press
the steel ball to fill the high pressure chamber with engine
oil.
6. Remove the hydraulic compensator from the container,
slowly press the steel ball and plunger to remove engine
oil from the high pressure chamber.
7. Place the valve clearance adjuster in container C and use
a steel wire with a diameter of 0.5 mm to slowly press the
steel ball.
9. Remove the hydraulic compensator from the container, set
the plunger to the top position, and check if it moves. If
the hydraulic compensator (plunger) settles or moves,
repeat steps 7-9 and fill the valve clearance hydraulic
compensator with engine oil. If, after performing the above
actions, the plunger continues to settle and move, the
hydraulic compensator must be replaced.
