Installation
shaft with a wrench.
5. Remove the timing chain
(b) Remove the VVT phase shifter mounting bolts and remove
the phase shifters.
new
Note:
(a) Fix the hex part of the camshaft with a wrench, and rotate the
camshaft counterclockwise to loosen the tension in the chain
between the VVT phase shifters.
(c) Attach the VVT phase shifter to the distributor
shaft with a bolt.
ÿ Locking the camshaft anywhere other than the hexagon part or
tightening the timing chain is strictly prohibited!
(b) Remove the timing chain.
ÿ Stage 1. Tightening torque: 40±3 N•m.
ÿ Step 2. Rotate 90°.
Clue:
Note:
7. Installation of VVT system phase shifters
ÿ To prevent pistons from colliding with valves, do not rotate the
crankshaft and camshaft too much.
ÿ The intake and exhaust valve phase shifters are marked “IN”
and “EX” respectively.
(a) Install the VVT phase shifter on the camshaft as shown.
6. Removing the inlet / outlet valve phase shifters
(a) Fix the hexagon part of the distributor
(b) Fix the hex part of the distributor
shaft with a wrench.
81
Chapter X. Cylinder head
