groups
Paint mark
depending on the
Chapter XI. Cylinder block
91
(c) Grouping of connecting rod bearings:
0.044 mm.
(d) Select the connecting rod bearing shell according to the bore
diameter of the connecting rod bottom head and crankpin.
Nominal value of radial clearance: 0.022-
Color/group Reference value (mm)
Clue:
(a) Apply a small amount of engine oil to the piston groove.
(b) Install 2 compression rings and oil wiper and
ÿ If it is not possible to find the connecting rod bearing shell, the
crankshaft or connecting rod must be replaced.
Yellow/3
1.393-1.399 mm
put test marks on the top of the rings.
ÿ A: First compression ring
ÿ B: Second compression ring
Blue/2
1.388-1.394 mm
12. Selection of piston rod
Red/1 1.383-1.389 mm
ÿ C: Oil ring
(a) All four pistons and connecting rods in one engine must
belong to the same quality group.
13. Installation of compression and oil scraper rings
Assembly
